Roll-up self-repairing door
ZipGO®
ZipGO®
Price list from 4.016€ and discounted 3.890€ for purchases of doors to be dialed in series.
Sales record 2022 as a self-repairable GLG port.
What is it?
It is the ultimate rapid door, designed to compartmentalize environments for various purposes. It offers high flexibility of use, thanks to its self-repairing feature. It can be used both internally and externally and is frequently employed in conjunction with the movement of people or industrial machinery.
Speed › Up to 2.2 m/sec
Wind resistance › Class 2*
* up to Class 4 avoiding the self-repairing of the door
Main features. Let’s find out together.
Self-repairing
The special sliding system allows the PVC fabric to repair itself in the event of an impact, enabling the tarp to extend and retract without any intervention by an operator.
Very fast
The ZipGO base is capable of accommodating a high volume of rapid and continuous movements, thanks to its specific sliding design of the curtain and powerful acceleration engines that enhance its response speed.
3
Flexible and safe
The ZipGO is a self-repairing roll-up door, devoid of structural bars, and designed with a side hinge guide. It is engineered to facilitate significant traffic flow while guaranteeing utmost intrinsic safety due to the complete absence of rigid elements in the passage area.
TestVelocità massima std di apertura 2,2m/s
Approved by the internal laboratory of R&D on the opening speed of the PVC fabric, measured by the step on the ground at the arrival to the upper beam.
Features
Self-repairable
Secure
Fast
The ZipGO range is equipped with SOMMER motors capable of developing a top speed of 2.2 m/s. With special electronic processing, speeds of up to 3.0 m/s.
Silent
sealant
Low-energy
The ZipGO is the basic range for GLG roll-up self-reparing doors. For more specific solutions it is advisable to view the versions tailored to your sector.
Used mainly to
Storage
GDO
Food industry
Also recommended for
Laboratories
Chemistry ATEX
Automotive
Generic industry
So, who’s it meant for?
ZipGO has been designed to streamline the logistics for companies with rapid production cycles, aiming to minimize accidental incidents to the utmost extent.
ZipGO is the roll-up door with the highest certified performance index, offering unmatched reliability, safety, and versatility in the market.
Combination of elasticity and tension
Side hinges applied to the flexible PVC fabric ensure dynamic and non-stop movement even after an accidental impact.
High speed self-repairing door
The self-repairing PVC fabric* is automatically reinnected even after accidental breakage of any vehicle.
* The R&D department specifies that self-repairable PVC fabric refers to a tarpaulin capable of nesting in the polyethylene side rails without requiring any manual intervention by operators. However, it should be noted that if the mantle is pierced, the chemical composition is unable to repair the molecules independently to restore physical tearing.
Here is a self-reparing door before the impact of a vehicle that is trying to cross the threshold between the two environments
Let us avoid unnecessary production blocks.
As a result, the special sliding system, which combines a polyethylene profile with a special system of spring shock absorbers, allows not only to avoid the door breaking but also to return as soon as possible to the normal production process, in practically no time.
Impact between the vertical crest of the fork lift truck and the self-repairing ZipGO PVC door.
Physical reaction of the PVC fabric that comes out of the polyethylene guides during the phase of impact simulated by the medium that is passing
Automatic return of the PVC fabric after the end of the opening cycle by means of side hinges welded in adhesion to the PVC fabric sheet.
The self-repairing rapid door is ready to work again without any kind of production impediment, that is in normal condition
The operator can resume his work without interruptions and/or production blocks even after the impact with the door.
100%
Secure
#safetyfirst
0*
accidents
* are the incidents recorded in 2022 in the production environments where we installed the ZipGO as environment separation doors.
For complete security, the ZipGO is equipped with a set of technologies to ensure the safety of both objects and people in its vicinity.
The PVC fabric contains no rigid elements and is controlled by light barriers and inverters with absolute encoders, providing exceptional braking precision and millimeter-precise restart capabilities.
Optical ⓘ
Flexible mantle
Absolute encoder
Safety edge
Manual override
Polyethylene HDPE self-lubricating
Noise reduced to a minimum
The special guide system of ZipGO ensures maximum silence during both the closing and opening of the rapid door, especially when the hinges of the curtain are in operation.
Sound pressure
Average noise abatement of ~12 dbA*
* in an environment with a noise frequency of 100 db it is possible to attenuate it according to the A curve of 10/15 dba.
For the standard PVC fabric, the maximum sound insulation value verified by the R&D department between two environments with different acoustic pressure by means of a cathodophone is 10/15dbA. For higher values please evaluate the characteristics of the single or double terry covering.
SOMMER Engine
With 120 RPM, a torque of 35 Nm, integrated inverter, and Energy-saving GLG technology integrated into the bottom of the curtain, a consistent energy savings throughout the annual cycle is ensured.
* The energy saving parameters may vary % not proportional because the gravity system works on the cycles fully closed or open, ergo the savings could suffer substantial differences in terms of Kw/ h per day.
Saved energy
Consumption reduced to a minimum
A specific mechanical technology enables the door to operate partially through inertia during the descent phase of the curtain. This intelligent system ensures that 12% of the average daily cycles are effectively covered by this method, contributing to its efficiency.
Lintel at low height?
Lintel at low height?
Lintel at low height?
Lintel at low height?
Lintel at low height?
Lintel at low height?
Lintel at low height?
Lintel at low height?
Version
ZipGO Twin
The double-shaft door with lowered dumpster that saves space for your compartment.
Version
ZipGO Include
Choose the ZipGO variant that includes an integrated framework within the structure. This special door offers unparalleled aesthetic cleanliness.
* the control panel, control unit, encoder, and other electronic components remain concealed within the door structure, leaving only the open/close and stop buttons visible.
Accessories e finiture
Explore the range of accessories available for GLG branded rapid doors.
Additional “open” type button + box
Push-button type “open/emergency mushroom” + box
Button type “open” from panel
Button type “emergency mushroom” panel
Button type “close” black
“Two position” selector from panel
“Key” selector with two panel positions
Box for one button only
Box for two buttons
Offer advantages
Our contact person will handle your request within 48 hours of receiving the form. They will arrange for an initial inspection and prepare a customized quotation for your specific needs.
Learn more about the reliability of GLG Doors
The self-repairing door in 24h.
Giorgia CaiuloSales and customer care
Average writing time 1 day, 8 hours
ZipGO reviews
Quello che centinaia di clienti dicono di noi.
GLGTrust: Certified reviews
Ask for references
Still not convinced? Feel free to request more information about our company and our extensive portfolio of successful projects over the years. Our manager will be happy to explain some of our notable success stories.
RANGE
ZipGO
Start from 3.500€
Why
It is designed to facilitate the flow of traffic and ensure high safety within the company. It offers great flexibility of use, being suitable for both internal and external applications.
Speed › Opening up to 2.2 m/sec
Wind resistance › Class 2 / 3 / 4
v.ZipGO Cold
Start from 5.150€
Why
It is a rapid door with vertical technology capable of resolving the challenges associated with controlled transit between two environments with varying temperatures.
Transmittance › 3,7 W/m2 k
Opening speed › 1,8 m/s
v.ZipGO Food
Start from 3.850€
Why
The ZipGO Food rapid door is designed to separate processing, seasoning, or storage spaces within food environments.
Speed › Opening up to 2.2 m/s
Structure › Standard In acciaio INOX AISI 304 e Polietilene PE500
v.ZipGO Pharma
Start from 4.750€
Why
Designed to cater to the requirements of companies operating in sterile sectors, it aids in maintaining stable pressure environments, ensuring the room is as aseptic as possible.
Air permeability › Classe 4
Structure › HDPE + INOX
v.ZipGO Atex
Start from 6.500€
Why
Designed to cater to the requirements of companies operating in sterile sectors, it aids in maintaining stable pressure environments, ensuring the room is as aseptic as possible.
PVC fabric › Antistatic (Blue or Grey)
Structure › INOX AISI 306L *
* On request for special projects
v.ZipGO Conveyor
Start from 5.500€
Why
Flexible PVC doors designed to partition processing spaces operated by automated machines.
Speed › Opening up to 2.2 m/sec
Machinery Directive › Complies with the ENISO14120 standard
